SpringSeal360-Metric units
Product number |
(D) Bore diameter |
(d) Shaft diameter |
h(t) |
36001 |
6 |
2 |
3.3 |
36002 |
6 |
3 |
3.3 |
36003 |
7 |
2 |
3.3 |
36004 |
7 |
2.5 |
3.3 |
36005 |
7 |
3 |
3.3 |
36006 |
7 |
4 |
3.3 |
36007 |
8 |
3 |
3.3 |
36008 |
8 |
3.8 |
3.3 |
36009 |
8 |
4 |
3.3 |
36010 |
8 |
5 |
3.3 |
36011 |
9 |
4 |
3.3 |
36012 |
9 |
4.5 |
3.3 |
36013 |
9 |
5 |
3.3 |
36014 |
9 |
6 |
3.3 |
36015 |
9.5 |
4 |
3.3 |
36016 |
9.5 |
4.5 |
3.3 |
36017 |
9.5 |
5 |
3.3 |
36018 |
10 |
4 |
3.3 |
36019 |
10 |
5 |
3.3 |
36020 |
10 |
6 |
3.3 |
36021 |
12 |
5 |
3.3 |
36022 |
12 |
6 |
3.3 |
36023 |
12 |
7 |
3.3 |
36024 |
12 |
8 |
3.3 |
36025 |
12 |
8.5 |
3.3 |
36026 |
12 |
9 |
3.3 |
36027 |
13 |
5 |
3.3 |
36028 |
13 |
6 |
3.3 |
36029 |
13 |
6.8 |
3.3 |
36030 |
13 |
7 |
3.3 |
36031 |
13 |
8 |
3.3 |
36032 |
13 |
8.5 |
3.3 |
36033 |
13 |
9 |
3.3 |
36034 |
13 |
10 |
3.3 |
36035 |
14 |
6 |
3.3 |
36036 |
14 |
6.8 |
3.3 |
36037 |
14 |
7 |
3.3 |
36038 |
14 |
8 |
3.3 |
36039 |
14 |
9 |
3.3 |
36040 |
14 |
10 |
3.3 |
36041 |
15 |
6 |
3.3 |
36042 |
15 |
7 |
3.3 |
36043 |
15 |
8 |
3.3 |
36044 |
15 |
9 |
3.3 |
36045 |
15 |
10 |
3.3 |
36046 |
16 |
7 |
3.3 |
36047 |
16 |
8 |
3.3 |
36048 |
16 |
9 |
3.3 |
36049 |
16 |
10 |
3.3 |
36050 |
16 |
12 |
3.3 |
36051 |
17 |
10 |
3.3 |
36052 |
17 |
12 |
3.3 |
36053 |
17 |
13 |
3.3 |
36054 |
18 |
8 |
3.3 |
36055 |
18 |
9 |
3.3 |
36056 |
18 |
10 |
3.3 |
36057 |
18 |
11.4 |
3.3 |
36058 |
19.2 |
12.6 |
3.3 |
36059 |
20 |
33.4 |
3.3 |
36060 |
22 |
14.6 |
3.7 |
36061 |
24 |
16.6 |
3.7 |
36062 |
25 |
42.6 |
3.7 |
36063 |
26 |
18.6 |
3.7 |
36064 |
28 |
20.6 |
3.7 |
36065 |
30 |
22 |
4 |
36066 |
31 |
23 |
4 |
36067 |
31.5 |
23.5 |
4 |
36068 |
33 |
25 |
4 |
36069 |
35 |
27 |
4 |
36070 |
35.4 |
27.4 |
4 |
36071 |
35.5 |
27.5 |
4 |
36072 |
38 |
29.6 |
4.2 |
36073 |
40 |
31.6 |
4.2 |
36074 |
41 |
32.6 |
4.2 |
36075 |
42 |
33.6 |
4.2 |
36076 |
44.5 |
36.1 |
4.2 |
36077 |
45 |
36.6 |
4.5 |
36078 |
50 |
41 |
4.5 |
36079 |
51.5 |
42.5 |
4.5 |
36080 |
55 |
46 |
4.5 |
36081 |
56 |
47 |
4.5 |
36082 |
60 |
51 |
4.5 |
36083 |
61 |
52 |
4.5 |
36084 |
63 |
54 |
4.5 |
36085 |
65 |
56 |
4.5 |
36086 |
66 |
57 |
4.5 |
36087 |
69 |
60 |
4.5 |
36088 |
70 |
60 |
5 |
36089 |
71 |
61 |
5 |
36090 |
75 |
65 |
5 |
36091 |
76 |
66 |
5 |
36092 |
80 |
70 |
5 |
36093 |
85 |
75 |
5 |
36094 |
90 |
79 |
5.5 |
36095 |
95 |
84 |
5.5 |
36096 |
100 |
89 |
5.5 |
36097 |
105 |
94 |
5.5 |
36098 |
110 |
97.6 |
6.2 |
36099 |
112 |
99.6 |
6.2 |
36100 |
115 |
102.6 |
6.2 |
36101 |
120 |
107.6 |
6.2 |
36102 |
125 |
112.6 |
6.2 |
36103 |
130 |
117 |
6.5 |
36104 |
132 |
119 |
6.5 |
36105 |
140 |
127 |
6.5 |
36106 |
150 |
136.6 |
6.7 |
36107 |
157 |
143.6 |
6.7 |
36108 |
160 |
146.6 |
6.7 |
36109 |
165 |
151.6 |
6.7 |
36110 |
170 |
156.6 |
6.7 |
36111 |
180 |
166.2 |
6.9 |
36112 |
185 |
171.2 |
6.9 |
36113 |
190 |
176.2 |
6.9 |
36114 |
200 |
185.6 |
7.2 |
36115 |
205 |
190.6 |
7.2 |
36116 |
210 |
195.6 |
7.2 |
36117 |
215 |
200.6 |
7.2 |
36118 |
220 |
205.6 |
7.2 |
36119 |
224 |
209.6 |
7.2 |
36120 |
225 |
210.6 |
7.2 |
36121 |
230 |
215.6 |
7.2 |
36122 |
240 |
225.6 |
7.2 |
36123 |
250 |
234.6 |
7.7 |
36124 |
260 |
244.6 |
7.7 |
36125 |
270 |
254.6 |
7.7 |
36126 |
275 |
259.6 |
7.7 |
36127 |
280 |
264.6 |
7.7 |
36128 |
290 |
274.6 |
7.7 |
36129 |
297 |
281.6 |
7.7 |
36130 |
300 |
284 |
8 |
36131 |
312 |
296 |
8 |
36132 |
332 |
316 |
8 |
